OxyRevo Heal 40 – 1.4 ATA Sitting Wheelchair Soft Type Hyperbaric Oxygen Chamber
Accessible & Comfortable Design
The OxyRevo Heal 40 is the world’s first soft-type sitting wheelchair hyperbaric chamber built for easy access and exceptional comfort.
Its spacious 170 cm (L) × 160 cm (W) × 190 cm (H) interior, sturdy aluminium base, and wheelchair ramp make entering and exiting effortless.
Users can also place a regular chair inside for a stable seated HBOT experience.
Technical Specifications
| Specification | Details |
|---|---|
| Working Pressure | 1.1 / 1.2 / 1.3 / 1.4 ATA (adjustable dial – no need to change valves) |
| Chamber + Frame Weight | 90 kg / 198 lbs |
| Dimensions | L 170 cm × W 160 cm × H 190 cm |
| Windows | 4 large double-layered |
| Material | Custom 5-ply PU (heat-welded, no glues, food grade silicone) |
| Sound Level | ≤ 50 dB (operating) |
| Colours | Grey, Black, Dark Blue, Red, Light Blue, Pink, Green, Purple, Gold (custom on request) |
| Oxygen System | 10 L/min @ 95–97 % O₂ (expandable to 15 or 20 L/min +) |
| Compressor | 85 L/min oil-free, maintenance-free |
| Air Cooler/Dehumidifier | 120 L/min dehumidifying, no freon/ice (air-con is optional extra) |
| Filters & Sterilisation | Dual air filters + anion generator + water nano steriliser |
| Safety | Emergency deflate valve + dual pressure gauges |
| Optional Extras | Red & Near-Infrared Light Therapy Devices, Anti-Static Mat, Water Chiller Air-conditioner |
| Warranty | 3-Year Standard (extendable), 2-Year Commercial |
Premium OxyRevo Features
-
Wheelchair / Chair Compatible Design – Easy ramp access and comfortable seated layout
-
Custom OxyRevo Valves – Precision-engineered for reliability
-
Curved Dual YKK Zippers – 70 % less effort vs straight zippers
-
Laser-Etched Labels – Durable UV-printed (no paper stickers)
-
Dual Pressure Display – Inside & outside aviation-grade gauges
-
Extra Quiet Relief Valves – Even airflow for silent operation
-
Filtration and Anion Air Purification – Removes PM 2.5 and odours for fresh air
-
Heat-Welded Seams – Non-toxic and environmentally safe
- Seals – Food grade silicone
Specialised custom made Oxygen Concentrator
Unlike typical HBOT compressors that lose oxygen output under pressure, OxyRevo’s patented system maintains up to 10 L/min even at 2 ATA, ensuring consistent oxygen delivery and better physiological results.
Efficient Air Cooling & Purification
The built-in dual air dehumidifier (120 L/min) keeps the chamber dry and comfortable while the anion and nano-water sterilisation system eliminates bacteria, dust, and viruses—ideal for clinics and therapy centres. If chamber is to be used in a non air-conditioned room, we recommend purchase of the optional water chiller air-conditioner.
Payment & Delivery
-
Payment: Full payment before production (finance from ≈ $50/week via Handypay) CLICK HERE
-
Lead Time: Made to order (≈ 2-6 weeks)
-
Delivery: Door-to-door service to driveway/garage only
-
Shipping & Duties: Included (customs fees/taxes covered)
-
To Order: Provide shipping address, email & mobile for freight updates
-
Contact: WhatsApp +61 473 526 426 | Email contact@oxyrevo.com.au
Quick FAQs
Is it wheelchair-friendly? Yes – ramp entry and spacious interior.
Adjustable pressure? Yes – 1.1 to 1.4 ATA.
How quiet is it? ≤ 50 dB with OxyRevo quiet-valve tech.
Need oxygen tanks? No – built-in concentrator (95–97 % O₂).
